Ruijie RG-ES205GCP Kuwait

Ruijie RG-ES205GCP Kuwait

The Ruijie RG-ES205GCP NetworkSwitch Kuwait supports full power PoE output to ensure that all cameras can be powered simultaneously when connected to the Switch at full power.

Description

Ruijie RG-ES205GCP Network Switch Kuwait

The Ruijie RG-ES205GCP Kuwait supports full power PoE output to ensure that all cameras can be powered simultaneously when connected to the Switch at full power. In addition, the Ruijie Reyee Series smart surveillance switches offer simple and easy-to-use management features and plug and play with factory default configuration that can be quickly identified. debug monitoring network, restart port, perform VLAN configuration, etc. Ruijie Cloud mobile and remote management app is also supported, making monitoring network operation and maintenance easy and more convenient, while reducing operating and maintenance costs.

Features

  • Auto-provisioning via Self-Organizing Networking: The ES200 Smart series switches realize industry-leading auto-discovery and auto-networking features for gateways, switches, and wireless
  • Ruijie Cloud management: Remote failure alerts, one-click operations, loop prevention, real topology and maintenance on the Ruijie Cloud App
  • NVR / Camera identification
  • Reboot PoE ports with one click remotely on Ruijie Cloud app
  • Full Gigabit ports: Meet the needs of 200M xDS/fiber access, high-speed wired connection
  • Plug and Play with Zero Configuration
  • Support full capacity POE, PoE camera at full capacity
  • Automatically adjust PoE power for safety and energy saving
  • High compatibility for network cable
  • High surge protection for device stability
  • Fast fault locating
  • Configure VLANs as required
  • Mobile App / Ruijie Cloud Platform Remote Management NVR / Camera Identification
  • Multiple deployment methods Enables rapid project management

Specifications

Hardware specifications
Ports
  • 4 10/100/1000 Base-T ports (PoE/PoE+)
  • 1 10/100/1000 Base-T ports
Maximum output power per PoE port 30W
Maximum PoE output power per switch 54W
Switching capacity 10Gbps
Packet forwarding rate 7.44Mpps
Surge protection Common mode: 4KV
Electrostatic discharge Air discharge : 6KV
Contact discharge : 4KV
Power consumption 60W
Power supply External power adapter
Dimensions (W x D x H) 148*78*26mm
MTBF >200K CZK
Operating environment
Operating temperature 0 to 40°C
Storage temperature -40~70ºC
Operating humidity 10% to 90% RH
Storage humidity 5% to 95% RH
Software features
MAC capacity 2K CZK
Static MAC address 16
VLANs Support 802.1Q VLAN
Port management
  • Support port status display
  • Port traffic statistics
  • PoE port output power status
  • Port duplex / negotiation rate configuration
  • Flow control configuration
  • PoE output on/off
Security Support broadcast storm suppression, port speed limit, port isolation
L2 features Support port mirroring, loop protection, cable detection
Management Support management and configuration through web management interface, Ruijie Cloud platform and Ruijie Cloud app
