AVer MD120UI Medical Grade PTZ Camera Kuwait

Introducing the groundbreaking AVer MD120UI Kuwait, heralded as the world’s foremost PTZ camera tailored exclusively for patient monitoring purposes. Revolutionizing the healthcare landscape, this innovative device harnesses the prowess of cutting-edge AI technologies, streamlining the monitoring process and empowering healthcare professionals to uphold unwavering vigilance and responsiveness to their patients’ requirements.

Equipped with an impressive array of features, including a 20X optical zoom and unparalleled 4K imaging capabilities, coupled with an IR night view function, the AVer MD120UI Kuwait ensures unparalleled clarity in patient monitoring. Gone are the days of uncertainty and blind spots; this state-of-the-art camera delivers crystal-clear visuals, facilitating round-the-clock surveillance with unmatched precision and reliability. With its seamless integration into healthcare facilities, AVer MD120UI Kuwait stands as a beacon of efficiency and efficacy, elevating the standard of patient care to unprecedented heights.

Specifications

Camera

• Image Sensor
  • 1/2.8′ CMOS
• Effective Picture Elements
  • 8 Megapixels

• Output Resolutions
  • Resolutions: 4K / 1080p / 720p
  • Frame Rates: 60 / 59.94 / 50 / 30 / 29.97 / 25
• Minimum Illumination
  • 0.5 lux (50 IRE, F1.6, Max. AGC, 1/30)

• S/N Ratio
  • ≥ 50 dB
• Gain
  • Auto, Manual

• TV Lines
  • 1000 (Center / Wide)
• Shutter Speed
  • 1/1s to 1/10,000s

• Exposure Control
  • Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
• White Balance
  • Auto / Manual

• Optical Zoom
  • 20X
• Digital Zoom
  • 1X

• Total Zoom
  • 20X
• Viewing Angles
  • DFOV: 69.2° (Wide) to 4.1° (Tele)
  • HFOV: 62.3° (Wide) to 3.6° (Tele)
  • VFOV: 37.7° (Wide) to 2.1° (Tele)

• Focal Length
  • f = 4.5 mm (Wide) to 90 mm (Tele)
• Aperture (Iris)
  • F = 1.8 (Wide) to 4.7 (Tele)

• Minimum Working Distance
  • 0.1 m (Wide) , 1.2 m (Tele)
• Pan / Tilt Angles
  • Pan: ±170°, Tilt: +90° / -30°

• Pan / Tilt Speed (Manual)
  • Pan: 0.1° to 100° / sec, Tilt: 0.1° to 100° / sec
• Preset Speed
  • Pan: 200° / sec, Tilt: 200° / sec
• Preset Positions
  • 10 (IR), 256 (RS-232, RS-422, IP)
• Camera Control – Interfaces
  • RS-232 / RS-422 / Ethernet
• Camera Control – Protocols
  • VISCA (RS-232 / RS-422 / IP), CGI (IP)
• Image Processing
  • Mirror / Flip / Freeze / WDR / BLC
• Power Frequencies
  • 50 Hz, 60 Hz

AI Function

• Mode
  • Eye Tracking

Privacy

• Protection Mode
  • Privacy Mode, Privacy Indicator

General

• Power Requirement
  • 12V
• Power Consumption
  • 24W

• PoE
  • PoE+ (IEEE802.3at)
• Dimensions
  • 180(W) x 145(D) x 183.5(H) mm

• Net Weight
  • 1.7 ± 0.1 kg
• Housing Material
  • Anti-UV

• Application
  • Indoor
• IR Night Vision
  • Yes

• Security
  • Kensington Slot
• IR Remote Control
  • Yes

• Operating
  • Temperature: 0 °C to +40 °C
  • Humidity: 20% to 80%
• Storage Conditions
  • Temperature: -20 °C to +60 °C
  • Humidity: 20% to 95%

Audio

• Channels
  • 2ch Stereo
• Codec
  • AAC-LC (48K)

• Built-in Microphone
  • 1 (Omni-Directional)

Interface

• Video Outputs
  • HDMI, IP, USB
• Audio Outputs
  • HDMI, IP, USB

• Audio Inputs
  • N/A

IP Streaming

• Resolution
  • 4K 60fps
• Network Video Compress Formats
  • H.264, H.265, MJPEG

• Maximum Frame Rate
  • 4K 60fps
• Bit-Rate Control Modes
  • VBR, CBR

• Range of Bit-Rate
  • 512Kbps to 64Mbps
• Network Interface
  • 10 / 100 / 1000 Base-T

• Multi-Stream Capability
  • 2 (RTSP / Web page), 4K 60fps Max.
• Network Protocols
  • IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP RTP/RTCP, RTSP, RTMP,VISCA over IP

USB

• Connector
  • USB 3.0 (Type-B)
• Video Formats
  • MJPEG

• Maximum Video
  • 2160p
• USB Video Class (UVC)
  • UVC 1.1

• USB Audio Class (UAC)
  • UAC 1.0

Web UI

• Live Video Preview
  • Yes
• Camera PTZ Control
  • Pan, Tilt, Zoom, Focus, Preset Control

• Camera / Image
  • Exposure, White Balance, Picture
• Network Configuration
  • DHCP, IP Address, Gateway, Subnet Mask, DNS

Software Tools

• IP Search and Configuration Tool
  • Support Windows® 7 or later
• PTZ Management
  AVer ViewCare
  • Support Windows® 7 or later

• PTZ Control Panel
  • Supports iOS & iPadOS® 11 or later
• Camera Setting Tool
  • Supports Windows® 7 or later, macOS® 10.14 or later

Warranty

• Camera
  • 3 Years
• Accessories
  • 1 Year

• Package Contents
  • Camera, Drilling Paper, Ceiling Mount Bracket, QR Code Card, Cable Fixing Plate, M2 x 4 mm Screw (x3), Power Adapter & Power Cord, 1/4”-20 L=6.5 mm Screw (x2), Remote Control, M3 x 6 mm Screw (x3), USB Cable (Type-B)
• Optional Accessories
  • AVer CL01 PTZ Camera Controller, L-Type Wall Mount
