Tplink EAP653 Kuwait

Tplink EAP653 Kuwait

The Tplink EAP653 Kuwait can become part of the Omada Mesh, facilitating wireless connectivity between access points. By installing multiple Tplink EAP653 Kuwait access points.



Tplink EAP653 Kuwait

The Tplink EAP653 Kuwait Access Point, delivering lightning-fast WiFi 6 speeds that provide simultaneous 574 Mbps on the 2.4 GHz band and 2402 Mbps on the 5 GHz band, resulting in a total WiFi speed of up to 2976 Mbps. WiFi 6 technology also ensures that more devices can connect to your network with enhanced speed and efficiency.

The Tplink EAP653 Kuwait offers versatile power options, supporting both 802.3at PoE+ and DC power supply (available separately), allowing for flexible installation solutions. Its ultra-sleek design, with a compact footprint measuring only 160 mm × 33.6 mm, enables discreet placement throughout your home.

For centralized network management, the Tplink EAP653 Kuwait seamlessly integrates with Omada SDN. Whether you prefer local management or cloud-based control via web UI or the Omada app, this access point provides a comprehensive solution. Additionally, seamless roaming ensures uninterrupted video streaming and voice calls, even as multiple users move between locations.

For extended coverage and flexible deployment, the Tplink EAP653 Kuwait can become part of the Omada Mesh, facilitating wireless connectivity between access points. By installing multiple Tplink EAP653 Kuwait access points, you can expand the coverage area throughout your home or business, ensuring a seamless and reliable WiFi experience.


  • Ultra-Fast WiFi 6 Speeds : Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds.
  • High-Efficiency WiFi 6: More connected devices can enjoy faster speeds.
  • Centralized Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app.
  • 160 MHz Channel: Double the data at peak transmission times on a single stream with HE160.
  • Seamless Roaming: Video streams and voice calls are unaffected as users move between locations.
  • Omada Mesh : Enables wireless connectivity between access points for extended range and flexible deployment.
  • PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter NOT included) power supply for flexible installations.
  • Ultra-Slim Design: Φ160 mm × 33.6 mm elegant design brings more agility.

Technical Specs

Interface 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
Button Reset
Power Supply 802.3at PoE
12V DC (Power Adapter is NOT included)
Power Consumption EU : 13.5 W
Dimensions ( W x D x H ) 6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm)
Antenna Type Internal Omni

2.4 GHz : 2× 4 dBi

5 GHz : 2× 5 dBi

Mounting Ceiling /Wall Mounting (Kits included)

Junction Box Mounting

Wireless Standards IEEE 802.11ax/ac/n/g/b/a
Frequency 2.4 GHz and 5 GHz
Signal Rate 5 GHz : Up to 2402 Mbps

2.4 GHz : Up to 574 Mbps

Wireless Functions 1024-QAM

4× Longer OFDM Symbol


Multiple SSIDs (Up to 16 SSIDs, 8 for each band)

Enable/Disable Wireless Radio

Automatic Channel Assignment

Transmit Power Control (Adjust Transmit Power on dBm)



HE160 (160 MHz Bandwidth)

Seamless Roaming

Omada Mesh

Band Steering

Load Balance

Airtime Fairness


Rate Limit

Reboot Schedule

Wireless Schedule

Wireless Statistics based on SSID/AP/Client

Wireless Security Captive Portal Authentication

Access Control

Wireless Mac Address Filtering

Wireless Isolation Between Clients

SSID to VLAN Mapping

Rogue AP Detection

802.1X Support

WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Transmission Power CE :

<20 dBm(2.4 GHz, EIRP)

<23 dBm(5 GHz, Band1 & Band2, EIRP)

<30 dBm(5 GHz, Band3, EIRP)FCC :

<25 dBm (2.4 GHz)

<25 dBm (5 GHz)

Omada App Yes
Centralized Management Omada Hardware Controller (OC300)

Omada Hardware Controller (OC200)

Omada Software Controller

Omada Cloud-Based Controller

Cloud Access Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1, v2c, v3
System Logging Local/Remote Syslog Local/Remote Syslog
Web-based Management HTTP/HTTPS
L3 Management Yes
Multi-site Management Yes
Management VLAN Yes
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller.
Certification CE, FCC, RoHS
Package Contents EAP653

Ceiling/Wall Mounting Kits

Installation Guide

System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux
Environment Operating Temperature : 0–40 ℃ (32–104 ℉)

Storage Temperature : -40–70 ℃ (-40–158 ℉)

Operating Humidity : 10–90% RH non-condensing

Storage Humidity : 5–90% RH non-condensing
