Tplink TL-SF1005LP Kuwait

Tplink TL-SF1005LP Kuwait

The Tplink TL-SF1005LP Kuwait switch is equipped with five Ethernet ports, four of which support 802.3af PoE. This allows you to power various PoE-compatible devices like access points and IP phones directly from the switch. With a power budget of up to 67W.

Category:

Description

Tplink TL-SF1005LP Kuwait

The Tplink TL-SF1005LP Kuwait switch is equipped with five Ethernet ports, four of which support 802.3af PoE. This allows you to power various PoE-compatible devices like access points and IP phones directly from the switch. With a power budget of up to 67W, there’s ample power to meet your needs. If connected devices exceed this budget, the switch can intelligently disable power to network ports, starting with port 4.

Once installed, connected clients can enjoy blazing-fast speeds of up to 1 Gb/s and benefit from a 2K MAC Address table to ensure optimal network performance. Moreover, there’s no need for complicated installation or configuration with the Tplink TL-SF1005LP Kuwait 5-Port 10/100 Mb/s PoE-Compliant Unmanaged Switch from TP-Link. It simplifies the process of connecting additional Ethernet-enabled devices to your network.

Key Features:

  • Dedicated 4-Port PoE Switch with a 41W Budget for Versatile Applications
    • Compliant with the 802.3af PoE standard, delivering up to 15.4W on each PoE port.
    • The total 41W PoE power budget* across the 4× PoE ports supports various applications, including surveillance in offices, dormitories, and small businesses.
    • Fully compatible with IP cameras, access points, IP phones, computers, printers, and more.
  • Perfect for IP Surveillance with Extended Range of up to 250m
    • In extend mode, the Tplink TL-SF1005LP Kuwait offers PoE transmission distances of up to 250m**, making it ideal for deploying IP cameras in expansive areas.
  • Priority Video-Quality Assurance
    • The Tplink TL-SF1005LP Kuwait prioritizes critical applications like video monitoring. Ports 1-2 receive higher priority when you activate the one-touch Priority Mode, ensuring top-notch video quality.
  • Smart Power Management
    • When the total power consumption surpasses 41W, the intelligent power management system deactivates power to lower-priority ports. This safeguards the power supply to high-priority ports, preventing device overload.
    • The switch automatically detects and provides the necessary power for your PoE devices, safeguarding both PoE and non-PoE equipment from potential damage.
  • Robust Metal Casing
    • The Tplink TL-SF1005LP Kuwait features a durable metal casing, protecting its internal components and ensuring a long product lifespan.
    • Rigorously tested for reliability, the TL-SF1005LP delivers consistent switching performance you can rely on.

Technical Specs

HARDWARE FEATURES
Interface
  • 5× 10/100 Mbps RJ45 Ports (Ports 1–4 support 802.3af PoE)
  • AUTO Negotiation
  • AUTO MDI/MDIX
Network Media
  • 10BASE-T : UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
  • 100BASE-TX : UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
Physical Security Lock Yes
External Power Supply External Power Adapter (Output : 53.5 V DC / 0.81 A)
Packet Forwarding Rate 0.744 Mpps
PoE Ports (RJ45)
  • Standard : 802.3 af compliant
  • PoE Ports : Ports 1–4
  • Power Supply : 41 W
Mac Address Table 2K
Jumbo Frame 2 KB
Switching Capacity 1 Gbps
Dimensions ( W x D x H ) 3.9×3.9×1.0 in (100×98×25 mm)
Max Power Consumption
  • 1.9 W (220 V / 50 Hz, no PD connected)
  • 47 W (220 V / 50 Hz, with 41 W PD connected)
Max Heat Dissipation
  • 6.48 BTU/h(no PD connected)
  • 160.27 BTU/h(with 41 W PD connected)
SOFTWARE FEATURES
Transmission Method Store-And-Forward
Advanced Functions
  • Compatible With IEEE 802.3af/at Compliant PDs
  • Extend Mode Button (Ports 1–4)
  • Priority Mode Button (Ports 1–2)
  • Mac Address Auto-Learning And Auto-Aging
  • IEEE802.3x Flow Control For Full-Duplex Mode and Backpressure for Half-Duplex Mode
OTHERS
Package Contents
  • TL-SF1005LP
  • Power Adapter
  • Installation Guide
Environment
  • Operating Temperature : 0–40 ℃ (32–104 ℉)
  • Storage Temperature : -40–70 ℃ (-40–158 ℉)
  • Operating Humidity : 10–90% RH non-condensing
  • Storage Humidity : 5–90% RH non-condensing
