Ubiquiti U6Lite Kuwait

Ubiquiti U6Lite Kuwait

The Ubiquiti U6Lite Kuwait can be mounted horizontally in the ceiling to cover a high-density environment, or mounted vertically on the wall to extend its range.

Description

Ubiquiti U6Lite Access Point Kuwait

The Ubiquiti U6Lite Kuwait is a 2×2 Wi-Fi 6 access point that delivers up to 1.5 Gbps aggregate radio rate with 5 GHz (MU-MIMO and OFDMA) and 2.4 GHz (MIMO) radios. Mount Ubiquiti U6Lite Kuwait horizontally in the ceiling to cover a high-density environment, or mount it vertically on the wall to extend its range. The Ubiquiti U6Lite Kuwait has a compact and nano-sized design, so it can use nanoHD covers and mounting accessories.

Features :

  • 2×2 high-efficiency Wi-Fi 6
  • 5 GHz band 2×2 MU-MIMO and OFDMA with radio rate of 1.2 Gbps
  • 2.4 GHz band 2×2 MIMO with radio rate of 300 Mbps
  • Gigabit Ethernet, powered with 802.3af PoE (PoE injector not included)
  • Compatible with UAP-nanoHD covers and recessed mounting bracket
  • Less interference with OFDMA
    • With OFDMA, Wi-Fi 6 access points not only deliver higher-volume data packets, but tactically parse and deliver data to multiple devices simultaneously, drastically improving their upload and download speeds.
  • Two-stream, high-efficiency Wi-Fi 6 technology
    • Wi-Fi 6 APs deliver an aggregate radio rate of up to 1.5 Gbps with 5 GHz (2×2 MU-MIMO and OFDMA) and 2.4 GHz 2×2 MIMO radios.
  • Powerful, wider wireless coverage
    • The Ubiquiti U6Lite Kuwait access point utilizes Wi-Fi 6 technology to provide strong and expansive wireless coverage to all enterprise networking environments.
  • Simultaneously connect to more devices
    • Create and support over 300 distinct client connections.
  • Easily set up and grow your network
    • The Ubiquiti U6Lite Kuwait seamlessly integrates with the UniFi Network Application and simplifies network bridging.

Technical Specifications

Mechanical

  • Dimensions : Ø160 x 32.65 mm (Ø6.3 x 1.3″)
  • Weight :
    • Without Mount : 300 g (10.6 oz)
    • With Mount : 315 g (11.1 oz)
  • Enclosure Characteristics : Polycarbonate 110 and ADC12 Die Casting
  • Mounting Characteristics : Polycarbonate, SGCC Steel

Hardware

  • Processor Specs : 880 MHz MIPS 1004 KEc
  • Memory Information : 256 MB
  • Management Interface : Ethernet In-Band
  • Networking Interface : (1) 10/100/1000 Mbps Ethernet RJ45
  • Buttons : Factory Reset
  • LEDs : White/Blue
  • Power Method : 802.3af PoE, Passive PoE (48V)
  • Power Supply : 802.3af PoE; 48V, 0.32A PoE Adapter (Not Included)
  • Supported Voltage Range : 44 to 57VDC
  • Max. Power Consumption : 12W
  • Max. TX Power
    • 2.4GHz : 23 dBm
    • 5GHz : 23 dBm
  • MIMO :
    • 2.4GHz : 2 x 2-
    • 5GHz : 2 x 2
  • Throughput Speeds
    • -2.4GHz : 300 Mbps
    • 5GHz : 1201 Mbps
  • Antenna Gain
    • 2.4GHz : 2.8 dBi
    • 5GHz : 3 dBi
  • Operating Temperature : -30 to 60° C (-22 to 140° F)
  • Operating Humidity : 5 95% Noncondensing
  • Certifications : CE, FCC, IC

Software

  • WiFi Standards
    • 802.11a/b/g
    • WiFi 4/Wi-Fi 5/Wi-Fi 6
  • Wireless Security : WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
  • BSSID 8 per Radio
  • VLAN : 802.1Q
  • Advanced : QoS Per-User Rate Limiting
  • Guest Trafc Isolation : Supported
  • Concurrent Clients : 300+

Supported Data Rates (MBPS)

  • 802.11a : 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  • 802.11n (Wi-Fi 4) : 6.5 Mbps to 300 Mbps (MCS0 MCS15, HT 20/40)
  • 802.11b : 1, 2, 5.5, 11 Mbps
  • 802.11g : 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  • 802.11ac : (Wi-Fi 5) : 6.5 Mbps to 866.7 Mbps (MCS0 MCS9 NSS1/2, VHT 20/40/80)
  • 802.11ax : (Wi-Fi 6) 6.3 Mbps to 1.2 Gbps (MCS0 MCS11 NSS1/2, HE 20/40/80)
