The Tplink Archer-AX90 Kuwait high-speed Wi-Fi 6 (802.11ax) router offers impressive throughput of up to 6579 Mb/s across the 2.4 GHz and dual 5 GHz bands, enabling you to allocate specific frequencies to your wireless smart devices, laptops, and gaming systems.



Tplink Archer-AX90 Kuwait

Experience seamless 4K video streaming, online gaming, and internet browsing throughout your home with the Tplink Archer-AX90 Kuwait Wireless Tri-Band 2.5G & Gigabit Router. Connect it to your compatible cable or DSL modem for blazing-fast performance. This high-speed Wi-Fi 6 (802.11ax) router offers impressive throughput of up to 6579 Mb/s across the 2.4 GHz and dual 5 GHz bands, enabling you to allocate specific frequencies to your wireless smart devices, laptops, and gaming systems to prevent interference.

Moreover, the 2.5G and 1G LAN/WAN combo ports empower you to harness the full potential of multi-Gig internet connections. For effortless network management, utilize the TP-Link Tether app, which simplifies tasks such as network configuration, guest network setup, and parental controls. Enjoy a superior online experience with the Archer-AX90 Kuwait Router.

Key Features:

  1. Outstanding Performance: The Tplink Archer-AX90 Kuwait is driven by a robust 1.5 GHz quad-core processor, delivering a remarkable combined bandwidth of up to 6.6 Gb/s across two distinct 5 GHz bands and the 2.4 GHz frequency when used with compatible devices.
  2. Reliable Connectivity: Equipped with eight high-powered external antennas, this router employs OFDMA and MU-MIMO technologies to efficiently transmit data to multiple devices simultaneously. Beamforming technology ensures broad signal coverage.
  3. Multi-Gig Internet: Take full advantage of multi-Gig internet services with the 2.5G and 1G WAN/LAN combo ports provided by the Tplink Archer-AX90 Kuwait.
  4. Wired Connections: Easily connect wired devices, including computers, smart TVs, and game consoles, to the router via its four Gigabit Ethernet LAN ports.
  5. OneMesh Network: Expand your wireless coverage by adding TP-Link OneMesh compatible routers and devices to your network. These devices operate under a single network ID (SSID) and seamlessly switch you to the strongest signal as you move around your home.
  6. USB Sharing: Share photos, videos, and files across your network by connecting storage devices to the USB 3.1 Gen 1 and USB 2.0 Type-A ports. Note that USB 3.1 Gen 1 is equivalent to USB 3.0.
  7. User-Friendly Tether App: Effortlessly configure and manage your network from virtually anywhere using the TP-Link Tether app, available for both Android and iOS.
  8. TP-Link HomeShield: Ensure the security of your home network with TP-Link’s premium security services, which automatically detect online threats. Additionally, enjoy a suite of parental controls and quality of service features to tailor your family’s online experience.
  9. VPN Access: Enhance your online security while using public Wi-Fi hotspots by establishing secure OpenVPN and PPTP VPN connections to your home network.
  10. Network Security: Your wireless network is safeguarded with WPA/WPA2/WPA3 and WPA/WPA2-Enterprise encryptions. The Tplink Archer-AX90 Kuwait also includes an SPI firewall to deter potential network intruders.

Technical Specs

Standards Wi-Fi 6

IEEE 802.11ax/ac/n/a 5 GHz

IEEE 802.11ax/n/b/g 2.4 GHz

WiFi Speeds AX6600

5 GHz : 4804 Mbps (802.11ax, HE160)

5 GHz : 1201 Mbps (802.11ax)

2.4 GHz : 574 Mbps (802.11ax)

WiFi Range 4 Bedroom Houses

8× Fixed High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas

Beamforming Concentrates wireless signal strength towards clients to expand WiFi range

High-Power FEM Improves transmission power to strengthen signal coverage

4T4R Multiple streams in the same band strengthen the fault tolerance in transmission

WiFi Capacity Very High

Allocate devices to different bands for optimal performance

Simultaneously communicates with multiple MU-MIMO clients

Simultaneously communicates with multiple Wi-Fi 6 clients

Airtime Fairness
Improves network efficiency by limiting excessive occupation

Access an extra band to reduce congestion

8 Streams
Connect your devices to more bandwidth

Working Modes Router Mode
Access Point Mode
Processor 1.5 GHz Quad-Core CPU
Ethernet Ports 1× 2.5 Gbps WAN/LAN Port

1× 1 Gbps WAN/LAN Port

3× 1 Gbps LAN Ports

USB Support 1× USB 3.0 Port

1× USB 2.0 PortSupported Partition Formats :


Supported Functions :

Apple Time Machine

FTP Server

Media Server

Samba Server

Buttons Wi-Fi On/Off Button

Power On/Off Button

LED On/Off Button

WPS Button

Reset Button

Power 12 V ⎓ 3.3 A
WiFi Encryption WPA



WPA/WPA2-Enterprise (802.1x)

Network Security SPI Firewall

Access Control

IP & MAC Binding

Application Layer Gateway HomeShield Security

Real-Time IoT Protection

Malicious Site Blocker

Intrusion Prevention System

DDoS Attack Prevention

Home Network Scanner

Guest Network 1× 5 GHz-1 Guest Network

1× 5 GHz-2 Guest Network

1× 2.4 GHz Guest Network

VPN Server OpenVPN


Protocols IPv4


Service Kits HomeShield
OneMesh OneMesh Supported

Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh helps you create a more flexible network that covers your entire home with TP-Link OneMesh products.


Parental Controls HomeShield Parental Controls

Custom Profiles

Professional Content Filter Library

Family Time


Off Time

Time Rewards

Family Online Time Ranking

Pause the Internet

Weekly and Monthly Reports

WAN Types Dynamic IP

Static IP




Quality of Service QoS by Device
Cloud Service Auto Firmware Upgrade

TP-Link ID


NAT Forwarding Port Forwarding

Port Triggering



Virtual Server


IGMP Snooping



DHCP Address Reservation

DHCP Client List





Management Tether App


Dimensions (W×D×H) 12.2 × 8.1 × 6.8 in
(311 × 207 × 174 mm)
Package Contents Wi-Fi Router Archer AX90

Power Adapter

RJ45 Ethernet Cable

Quick Installation Guide

System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)

Certifications FCC, CE, RoHS
Environment Operating Temperature : 0℃~40℃ (32℉ ~104℉)

Storage Temperature : -40℃~70℃ (-40℉ ~158℉)

Operating Humidity : 10%~90% non-condensing

Storage Humidity : 5%~90% non-condensing

WiFi Transmission Power CE :





<24dBm{5.47GHz~5.725GHz }

<30dBm{2.4GHz &5.15GHz~5.25GHz&5.725GHz~5.825GHz }

WiFi Reception Sensitivity 2.4GHz :

11n HT20 MCS0 : -95dBm

11ax HE20 MCS11 : -64dBm

11ax HE40 MCS11 : -62dBm

5GHz-1 :

11ac VHT20 MCS0 : -92dBm

11ax HE20 MCS11 : -61dBm

11ax HE40 MCS11 : -58dBm

11ax HE80 MCS11 : -55dBm

5GHz-2 :

11ac VHT20 MCS0 : -95dBm

11ax HE20 MCS11 : -61dBm

11ax HE40 MCS11 : -58dBm

11ax HE80 MCS11 : -55dBm

11ax HE160 MCS11 : -53dBm
