The Tplink TL-SF1006P Kuwait is a professional-grade high-power switch featuring 4 PoE+ ports. This switch is equipped with 6 x 10/100 Mbps RJ45 ports and 4 x PoE+ ports designed to handle both data transfer and power delivery over individual cables.

Category:

Description

Tplink TL-SF1006P Kuwait

The Tplink TL-SF1006P Kuwait is a professional-grade high-power switch featuring 4 PoE+ ports. This switch is equipped with 6 x 10/100 Mbps RJ45 ports and 4 x PoE+ ports designed to handle both data transfer and power delivery over individual cables. These PoE ports are intelligent, capable of automatically detecting and supplying power to IEEE 802.3af compliant Powered Devices (PDs).

Supporting PoE transmission for surveillance applications over distances of up to 250 meters, the Tplink TL-SF1006P Kuwait adheres to the 802.3af/at PoE standard, allowing for a maximum power delivery of 30 watts on each PoE port. This switch is highly versatile, fully compatible with a wide range of devices, including IP cameras, access points, IP phones, computers, printers, and more.

To ensure efficient power management, the switch employs intelligent mechanisms. When the total power consumption surpasses 67 watts, it automatically prioritizes power supply to high-priority ports, preventing power overload and safeguarding your equipment. Additionally, it’s equipped with safeguards to detect and provide the precise power needed by your PoE devices, safeguarding both your PoE and non-PoE devices from potential damage.

Housed in a durable metal casing, the Tplink TL-SF1006P Kuwait is built to withstand the test of time, guaranteeing a long and reliable product life.

Quick Features

  • 6× 10/100 Mbps RJ45 ports
  • 4× PoE+ ports transfer data and power on individual cables
  • Works with IEEE 802.3af/at compliant PDs
  • Up to 250m data and power transmitting range under Extend Mode**
  • Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
  • Supports PoE Power up to 30 W for each PoE port
  • Supports PoE Power up to 67 W for all PoE ports*
  • Plug and play with no configuration required

Technical Specs

HARDWARE FEATURES
Interface
  • 6× 10/100 Mbps RJ45 Ports (ports 1–4 support 802.3af/at PoE+)
  • AUTO Negotiation
  • AUTO MDI/MDIX
Network Media
  • 10BASE-T : UTP category 3, 4, 5 cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 100BASE-TX : UTP category 5, 5e cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
Physical Security Lock Yes
External Power Supply External Power Adapter (Output : 53.5 V DC / 1.31 A)
Packet Forwarding Rate 0.8928 Mpps
PoE Ports (RJ45)
  • Standard : 802.3 af/at compliant
  • PoE Ports : Ports 1–4
  • Power Supply : 67 W
Mac Address Table 2K
Jumbo Frame 2 KB
Switching Capacity 1.2 Gbps
Dimensions ( W x D x H ) 6.2 x 4.0 x 1.0 in (158 x 101 x 25 mm)
Max Power Consumption
  • 1.9 W (220 V / 50 Hz, no PD connected)
  • 74 W (220 V / 50 Hz, with 67 W PD connected)
Max Heat Dissipation
  • 6.48 BTU/h(no PD connected)
  • 252.34 BTU/h(with 67 W PD connected)
SOFTWARE FEATURES
Transmission Method Store-And-Forward
Advanced Functions
  • Compatible With IEEE 802.3af/at Compliant PDs
  • Extend Mode Button (Ports 1–4)
  • Priority Mode Button (Ports 1–2)
  • Mac Address Auto-Learning and Auto-Aging
  • IEEE802.3x Flow Control For Full-Duplex Mode and Backpressure for Half-Duplex Mode
OTHERS
Certification FCC, CE, RoHS
Package Contents
  • TL-SF1006P
  • Power Adapter
  • Installation Guide
Environment
  • Operating Temperature : 0–40 ℃ (32–104 ℉)
  • Storage Temperature : -40–70 ℃ (-40–158 ℉)
  • Operating Humidity : 10–90% RH non-condensing
  • Storage Humidity : 5–90% RH non-condensing
