Cisco WAP321 Kuwait is equipped with a highly secure, high-speed 802.11n wireless networking which delivers enhanced throughput and extended range for bandwidth-intensive applications.

Description

Cisco WAP321 Access Point Kuwait

The Cisco WAP321 Kuwait Wireless-N Selectable-Band Access Point with Single Point Setup is a sleek, affordable, and easy-to-deploy device that delivers fast, highly secure wireless connectivity. It supports high-speed connections with Gigabit Ethernet LAN interface for demanding applications. The Cisco WAP321 bridges wired LANs together wirelessly, making it easier for small businesses to expand their networks.

Designed for growing organizations, the Cisco WAP321 Kuwait offers the ability to smoothly scale your network by bridging wired LANs together wirelessly, to reduce cabling and installation costs. It supports multiple Service Set Identifiers (SSIDs) to enable you to segregate traffic for different departments, users, and communication devices.

For companies that need to provide secure wireless guest access, the Cisco WAP321 offers captive portal support that lets you create a wireless hotspot with visitor authentication.

The Cisco WAP321 Kuwait is simple to set up and use, with intuitive wizard-based configuration to get you up and running in minutes. A sleek, compact design with flexible mounting options enables the access point to smoothly blend into any small business environment. Power over Ethernet (PoE) support makes the device easy to install without the need for separate power plugs or expensive new wiring.

To enhance reliability and safeguard sensitive business information data, the Cisco Wi-Fi Kuwait supports WiFi Protected Access (WPA2), encoding all your wireless transmissions with powerful encryption. 802.1X RADIUS authentication helps keep unauthorized users out. Single Point Setup is a controllerless multi-access point deployment technology that allows you to deploy and manage multiple access points in a simple and cost-effective way across your premises.

Single Point Setup provides a unique centralized method to administer and control wireless services across multiple devices. Via one access point on the LAN, you have a single view of the whole WLAN to replicate configuration, security, and management across all access points.

With the Cisco WAP321 Kuwait, you can build on your existing network to deliver high-performance wireless access with the scalability you need as your business grows and evolves.

Features

  • Cisco WAP321 Kuwait is equipped with a highly secure, high-speed 802.11n wireless networking which delivers enhanced throughput and extended range for bandwidth-intensive applications.
  • Wizard-based setup and configuration enables fast, simple deployment.
  • Single Point Setup controllerless multi-access point deployment and management technology makes configuration simple.
  • Gigabit Ethernet LAN interface provides high-speed connectivity for faster downloads and demanding applications.
  • Selectable-band wireless access lets you switch bands to minimize interference from other office devices and improve performance.
  • Cisco WAP321 Kuwait delivers robust security, including WPA2, 802.1X with RADIUS secure authentication, and rogue access point detection, helps protect sensitive business information.
  • Cisco Wi-Fi Kuwait has built-in support for PoE enables easy installation without the expense of additional wiring.
  • Workgroup Bridge mode lets you expand your network by wirelessly connecting to a second Ethernet network.
  • Cisco WAP321 Kuwait has elegant, compact design with internal antennas and versatile mounting kit enables installation on a ceiling, wall, or desktop.
  • Intelligent QoS prioritizes network traffic to keep critical network applications running at top performance.
  • Power-saving sleep mode and port control features help maximize energy efficiency.
  • Highly secure guest access enables safe wireless connectivity for visitors.
  • Cisco WAP321 Kuwait has support for IPv6 which lets you deploy future networking applications and operating systems without costly upgrades.

Technical Specs

Specifications

Description

Standards

IEEE 802.11n, 802.11g, 802.11b, 802.3, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460)

Ports

Ethernet, Power

Switch

Power button (on/off)

Buttons

Reset

Cabling type

Category 5e or better

LEDs

Power, Wireless, LAN

Operating system

Linux

Physical Interfaces

Ports

Gigabit Ethernet, 12V DC power with support for 802.3af PoE

Power supply

Not included with access point, but supports external power 12V DC power jack (Energy Star 2.0 compliant with Efficiency Level 5) and 802.3af PoE

Buttons

Power (on/off) push button; Reset button

Lock slot

Slot for Kensington lock

LED

Power, Wireless, Ethernet

Physical Specifications

Physical dimensions (W x D x H)

6.66 x 6.67 x 1.38 in. (169.08 x 169.42 x 35 mm)

Weight

0.606 lb or 275g

PoE

PoE

802.3af

Peak PoE power

10.6W

Network Capabilities

Network protocols

IEEE 802.11n, 802.11g, 802.11b, 802.3, 802.3u, 802.1X (security authentication), 802.1Q (VLAN), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460), RADIUS, syslog, HTTP/HTTPS, Simple Network Management Protocol (SNMP)

VLAN support

Yes

Number of VLANs

1 management VLAN plus 8 VLANs for SSID

Multiple SSIDs

8

802.1X supplicant

Yes

802.11d

No

SSID to VLAN mapping

Yes

Auto channel selection

Yes

Spanning tree

Yes

Load balancing

Yes

IPv6

Yes

  • IPv6 host support
  • IPv6 RADIUS, syslog, Network Time Protocol (NTP), etc.

Layer 2

802.1Q-based VLANS, 8 active VLANS plus 1 management VLAN

Security

WEP/WPA/WPA2

Yes, including Enterprise authentication

Access control

Yes, management access control list (ACL) plus MAC ACL

Secure management

HTTPS

Wi-Fi Protected Setup (WPS)

Yes (soft WPS, no hardware push button)

SSID broadcast

Yes

Rogue access point detection

Yes

Mounting and Physical Security

Multiple mounting options

Desktop installation; mounting bracket included for easy ceiling or wall mounting

Physical security lock

Kensington lock slot

Quality of Service

Quality of service (QoS)

Wi-Fi Multimedia Traffic Specification (WMM TSPEC)

Performance

Wireless throughput

Data rate =300 Mbps; actual client throughput will vary.

Recommended user support

Up to 32 connective users, 20 active users

Configuration

Web user interface

Built-in web user interface for easy browser-based configuration (HTTP/HTTPS)

Multi-Access Point Management

Single Point Setup

Yes

Maximum access points per cluster

8

Active clients per cluster

80

Management

Management protocols

Web browser, SNMP v3, Bonjour

Remote management

Yes

Event logging

Local, remote syslog, email alerts

Network diagnostics

Logging and packet capture

Web firmware upgrade

Firmware upgradable through web browser, imported/exported configuration file

Dynamic Host Configuration Protocol (DHCP)

DHCP client

IPv6 host

Yes

HTTP redirect

Yes, and captive portal

Wireless

Frequency

Selectable-band 2.4 GHz or 5 GHz (not concurrent)

Radio and modulation type

Single radio, orthogonal frequency division multiplexing (OFDM)

WLAN

802.11n

Operating channels

1 to 13 (depending on country)

Wireless isolation

Wireless isolation between clients

External antennas

None

Internal antennas

Internal fixed PIFA antenna

Antenna gain in dBi

2 dBi each antenna

Transmitted output power

  • 802.11b @ 11 Mbps : 17 dBm
  • 802.11g @ 54 Mbps : 13 dBm
  • 802.11n @ HT20HT40, MCS15 : 13 dBm

Receiver sensitivity

  • 802.11b : 11 Mbps @ –86 dBm
  • 802.11g : 54 Mbps @ –71 dBm
  • 802.11n : 300 Mbps @  –64 dBm

Wireless Distribution System (WDS)

Yes

Roaming

Yes

Fast roaming

802.11i pre-authentication

Active WLAN clients

Same as number of users : 32 max connected users, 20 active users recommended

Multiple SSIDs

8

Wireless VLAN map

Yes

WLAN security

Yes

Wi-Fi Multimedia (WMM)

Yes, with automatic power save, and Voice profile

Operating Modes

Access point

Access Point mode, WDS bridging, Workgroup Bridge mode

Environmental

Power

12V 1A DC input, and IEEE 802.3af compliant PoE

Certifications

FCC class B, CE, IC, Wi-Fi

Operating temperature

0° to 40°C (32° to 104°F)

Storage temperature

–20° to 70°C (–4° to 158°F)

Operating humidity

10% to 85% noncondensing

Storage humidity

5% to 90% noncondensing

Mean time between failures (MTBF)

492281 hours

Package Contents

  • Cisco WAP321 Wireless-N Selectable-Band Access Point with Single Point Setup
  • Ceiling/wall mounting kit
  • User guide on CD-ROM
  • Quick-start guide
  • Ethernet network cable
